list

A row or column whose children come from data: one itemfn(item) call per element of source. Reach for it for anything with a count you do not know up front: workspaces, notifications, search results, a thumbnail grid. For a fixed set of children, a row or column is simpler.

A scrolling thumbnail grid: a vertical list of two-image rows, decoded off-thread.

local paths = state("wallpapers", { "/usr/share/backgrounds/a.jpg", "/usr/share/backgrounds/b.jpg",
    "/usr/share/backgrounds/c.jpg", "/usr/share/backgrounds/d.jpg" })

-- Two per row: a vertical list of rows, keyed by the paths they hold.
local rows = paths:map(function(all)
    local out = {}
    for i = 1, #all, 2 do out[#out + 1] = { all[i], all[i + 1] } end
    return out
end)

local grid = list {
    width = 420,
    height = 300,
    spacing = 8,
    scroll = scroll("thumbs"),
    source = rows,
    key = function(pair) return table.concat(pair, "\n") end,
    itemfn = function(pair)
        local tiles = {}
        for i, path in ipairs(pair) do
            tiles[i] = image { source = path, async = true, fit = "cover", width = 206, height = 116 }
        end
        return row { spacing = 8, children = tiles }
    end,
}

return grid

What the example above draws

Keyed workspace buttons from a capability: workspaces cookbook.

Properties

list takes the common properties, plus the ones below. It takes no box properties: wrap it in a rect or column for a background.

Property	Type	Default	Behaviour
`source`	`any[]\|Bound`	Empty	Array; bind a signal to rebuild on change. Missing or `nil` (a capability before its first push) is an empty list; a `nil` hole ends it. More than 10000 items without `limit` is an error
`itemfn`	`fun(item: any): Node`	Required	Builds a node for every built item, visible or not
`key`	`fun(item: any): string`	None	Unique UTF-8 key per item; replaces the node’s `id`. Duplicates are refused. Without it items match by position
`limit`	`integer\|Bound`	None	Build at most this many items; above 10000 acts as 10000, `0` builds none
`direction`	`"Vertical"\|"Horizontal"\|Bound`	`"Vertical"`	Lays out as a `column` or a `row`
`spacing`	`number\|Bound`	`0`	Px between visible items along `direction`; negative values overlap them
`scroll`	`Bound`	None	A `scroll(name)` signal; makes the list a scrolling viewport along `direction` (scroll)

A list packs and aligns exactly like the row or column its direction names: its own align_v (vertical) or align_h (horizontal) packs the items.

When items rebuild

A list keeps the items it built until something that build read changes. A pass that finds nothing changed calls no itemfn and reads none of the items’ signals; it lays the kept items out again, about a third of the cost of building them. A change one item read builds that item alone; a change the list itself read builds every item, scrolled out of view or not.

Change	Builds again
A write to `source`, or to a signal under a `map` or `computed` bound to it	Every item
A write to a signal `key` read with `:get()`	Every item
A new `source`, `itemfn` or `key` value, a new `limit`, or a reload	Every item
A write to a signal an item’s `itemfn` call read with `:get()`, or bound to a property of that item at any depth, such as its `hover`	That item
A write to anything else, even on the same surface	Nothing

key carries each item’s state (tweens, a held image, a text field’s draft) onto its rebuilt node, and across reorders. Cap a long list with limit (a launcher’s top 50 matches), or hide it while closed so it freezes.

The engine sees signal reads only. An itemfn, key or item map that reads the clock, a mutable variable or a source table changed in place keeps what it read until a signal it read is written. A delay or pulse builds the items that read it again on every pass while one is pending or open. What to read instead: what a node reads again.

How do I…

Task	Answer
Lay out a grid	The example above: a `list` of `row`s, several items per row
Scroll a long list	Below
Keep items’ animations when the order changes	Give `key` a stable per-element string (an id from the data)
Show only the top N matches	`limit = 50`
Lay items out horizontally	`direction = "Horizontal"`
Filter as the user types	Bind `source` to a `map` of the query, as the textfield example does
Show an empty state	A sibling with `visible = items:map(function(all) return not all or #all == 0 end)`

Scroll a long list

Bound the size on the scrolling axis, then bind a scroll signal. max_height lets the list shrink to fit a few items and scroll past 200 px.

local names = {}
for i = 1, 40 do names[i] = "Item " .. i end

local items = list {
    width = 240,
    max_height = 200, -- grows with its items up to 200 px, then scrolls
    spacing = 2,
    scroll = scroll("items"),
    source = names,
    itemfn = function(name)
        return text { content = name, width = "Fill", padding = 6 }
    end,
}

Gotchas

Trap	Fix
A 2000-item `list` makes every update slow	Every item is laid out on every pass, and built whenever anything it read changes, visible or not. Cap it with `limit`, filter the `source`, or hide the list while it is closed
A `list` rebuilds though nothing it shows changed	Its `itemfn` or `key` is a new function each time the builder around it runs, as inside a function `child` that reads a signal. Define them once, outside the builder
A relative time (“3 min ago”) in an item stops updating	`itemfn` read the clock with `os.time()`. Bind the text to a `map` of `mantle.system` instead (what a node reads again)
A `list` of more than 10000 elements is refused	Set `limit`, or page the `source`
`duplicate key` error	`key` must return a different string for every element
`key` returning a number is refused	Return a string: `tostring(item.id)`
Items lose their state when one is added at the top	Without `key` they match by position. Add `key`
`background` on a `list` is refused	A list is not a box. Wrap it

See also: row and column, signals, input: scroll.

Source: vocabulary, list parser, layout as row or column.
